DMN-500L High Speed CNC Milling Machine Machining Centers
DMN-500L High Speed CNC Milling Machine Machining Centers
Обычная цена
$0.00
Обычная цена
$0.00
Цена со скидкой
Цена за единицу
/
за
Артикул:
DMN-500L High Speed CNC Milling Machine Machining Centers
Обычная цена
$0.00
Обычная цена
$0.00
Цена со скидкой
Цена за единицу
/
за
Описание
Описание
- Automatic Lubricating System:The positive displacement point-to-point lubrication is used to ensure that the lubricating oil is filled into each oil inlet and uniformly distributed on the machine.
- High-pressure backward flushing chip removal system:Two vertical motors are installed, one is used for backward flushing on two sides, and the other is used for the machine to directly cool the machined workpieces. The new backward flushing chip removal design is adopted to rapidly and thoroughly remove the chips attached to the inside of the machine. The high-pressure backward flushing chip removal system mainly carries away the machining heat generated in the chips to ensure the machining precision and the surface smoothness of the workpieces as well as the machine precision.
- Heat exchanger:The heat exchanger is used in the electrical box to ensure that the heat in the electrical box is extracted rapidly to maintain the temperature in the box and stabilize the operation of control system.
- Tricolour light:The tricolour light is arranged at the conspicuous position of the machine. When the machine is out of order, the tricolour light gives warning to the operator.
- One explosion-proof light is reasonably arranged on the two sides of the machine to fully ensure adequate lighting and protect the eyes from strong light.
- Oil-water separator: The oil-water separator separates the oil from the mixture in the event of oil-water mixing, and ensures the quality of cutting fluid. The recovered oil can be reused to save the cost.
Steady Triangular Structure Casting
- Test and analyze by using the most advanced finite element method and utilizing the pressure distribution of the computer simulation structure, the vibration source analysis and design changes, the structure location and other important mechanical and physical change factors in order to ensure that the design of all mechanical parts is improved to the optimum.
- Although the cost of iron castings is higher, Gamma adheres to use of the iron castings to manufacture the main components as the damping capacity of the iron castings is ten times higher than the steel castings. The reinforcing ribs are also arranged in Gamma iron castings in order to minimize the distortion and maximize the damping capacity. In addition, all Gamma iron castings are thoroughly inspected to ensure there is no crack before and after machining.
- The high-rigidity ultra-wide base and the chevron column are made of unibody HT300 cast iron to enjoy good stability, high rigidity and fine firmness and provide the most stable heavy load supporting force, and the workbench is not overhung and has excellent rigidity and stability in combination with the strengthened design of all shafts.
High Precision Guideway
- Each linear guideway uses the quenched steel linear rail, which is preloaded to achieve the zero clearance and the full load capacity in each direction.
- X-axis and Y-axis precision linear ball guideway.
- Z-axis precision linear roller guideway.
High Precision C3 Ball Screw
- The back clearance free, low noise and steady temperature rising control high-precision ball screw is used and is parallel to the guide rail through the precision measurement. The preloaded precision nut eliminates the back clearance.
Heavy cast iron base
- With the ultra-wide supporting anchor, the supporting area is large; with the supporting of box structure, strong stability and good rigidity, the product is suitable for heavy cutting machining.
Saddle
- The double-T ultra-wide structure extends the contact span of the saddle, enhances the torsional strength, strengthens the dynamic stability and ensures speediness and stationarity.
Table
- The ultra-thick and ultra-large table is arranged on X-aixs flatwise, the weight is distributed uniformly on the workbench, and the rigidity and the bearing capacity are ultra-strong to ensure that the guide rail of the machine tool is durable and holds precision for a long time.
Chevron column
- High-strength column structure design is adopted to bear heavy cutting and high-speed running without deformation. You will feel true powerful force. With the supporting of ultra-large and ultra-wide column, the internally reinforced layout and the grid intersecting arrangement of rib plates, the anti-torque ability is strong, so that the product is suitable for heavy cutting machining.
Head Stock
- The direct-link spindle is matched with the head stock with the rib strengthening design, featuring high sensitivity, no belt noise, low shock and no back clearance. The proportion of contact length between the spindle head and the column is proper, being golden proportion, providing steady support for the spindle, greatly improving the supporting area of the machine head and having very good machining stability.
